4-stream Music Streamer Monitor Audio IMS-4

IMS-4_Music_Streamer

Ends

Description
Specification

The IMS-4 music streamer’s discreet design allows it to be easily incorporated into any custom installation project. And, its slimline form ensures that it occupies just 1U of rack space.

BluOS allows the IMS-4 to stream lossless music at a quality of up to 24-bit/192khz to 4 zones in a home network. Accessed through the app, or one of the many supported integrated control systems, the multiple IMS-4 streamers can be combined to provide up to 64 zones, with each zone able to play together in perfect sync. It can also simultaneously play different streams to separate zones.

The IMS-4 can access millions of Master Quality Authenticated (MQA) recordings using BluOS technology to allow music to be heard exactly as the artist intended, anywhere in the home.

To power the music, the IMS-4 should be partnered with an installation amplifier such as our IA150-8C. The IMS-4 can be integrated with Crestron, Control4 and RTI and is compatible with other BluOS enabled devices.

Analogue and digital inputs allow the addition of a cable box or other non-network sources and to make them available in every zone. The IMS-4 even includes a system interrupt to let doorbells and fire alarms be heard.

Key Features

Featuring BluOS™ multi-room streaming technology
With four separate zones, different music can be streamed to four different rooms or areas
Allows streaming of Lossless music with MQA authentication
Integration with home automation services such as Crestron, Control4, RTI and other BluOS™ devices
Controllable using the BluOS™ Controller app for iOS, Android, MacOS and Windows
Compatible with Apple AirPlay 2
TIDAL Connect casting technology

Specifications

Channel Number / Rooms 4 Rooms
Free Internet Radio TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise, Radio.com
Output Connections Analogue - 4 x RCA StereoDigital SPDIF - 4 x Optical (TOSLINK)4 x Coaxial
Supported Operating Systems Plays music from Network Shares on the following operating systems - Microsoft Windows XP, 2000, Vista, 7 - 10 or higherApple Macintosh OSX 7 - 10 or higher
Sample Rate Up to 24-bit/ 192 kHz
Signal to Noise Ratio 110 dBA
Supported Cloud Services Spotify Connect, Amazon Music HD, TIDAL Connect, Deezer, Qobuz, Napster, KKBox, Bugs, Taihe Music Zone, SoundMachine, IDAGIO, Orastream
Sold As Single Unit
Supported File Formats MP3, AAC, WMA, WMA-L, OGG Vorbis, FLAC, ALAC,WAV, AIFF, MQA, HRA
Maximum Input Voltage (RMS) 2.2 V
Input Connections Analogue - RCA StereoDigital SPDIF - Optical (TOSLINK)USB - Type A (FAT32 Formatted)
User Interface Free Android, iOS, Windows applications available from the appropriate app store
Integration Partners Control4, RTI, Crestron, URC, roon, ELAN
Mains Operating Voltage 100 – 240 V 50/60 Hz

Dimensional parameters

Dimensions (Without Feet (HxWxD)) 43.1 x 438 x 236.1 mm (111/16 x 171/4 x 95/16")
Height (with feet) 45.1 mm (113/16")
Rack Height 1U
Width (including rack brackets) 482 mm (19")
Weight 2.8 kg (6 lb 3 oz)
