Active Subwoofer Monitor Audio Silver W-12 6G

Silver_W-12_6G

Pre-Order

Description
Specification

With its outstanding bass, the Silver W-12 provides the perfect sonic backdrop to your speaker set-up. The 500-watt amplifier gives incredible headroom, meaning more power doesn’t equal more distortion. And it’s intelligent, too, with features like Automatic Position Correction that learns the layout of the room and automatically corrects the acoustics of the music you hear. As a result, you can put your subwoofer wherever you like, with no restrictions, and still enjoy amazingly lifelike sound.

Key Features

Ultra long-throw 12-inch driver featuring ‘dished’ C-CAM cone
Triple suspension for ultimate linearity ensuring control at high power and excursions
Oversized black anodised 3-inch voice coil which provides high power-handling and low distortion
Powerful 500 W RMS Class-D amplifier with switching power supply provides instantaneous delivery of high current when required
DSP processing with all control features and crossover performed digitally
Automatic Position Correction plus automatic room setup feature using microphone for simple system optimisation
USB for firmware updates
Three preset EQ mode settings (Music, Movie, Impact)

Specifications

Trigger Input 5 – 12 V via 3.5 mm mono mini-jack socket
Amplifier Classification Class-D amplifier with switched-mode power supply (SMPSU)
Automatic detection Line Level >2 mV
Amplifier Output 500 W continuous
Low Pass Filter Alignment Active 4th order 24 db/octave
Input Level Requirements Standby after 20 minutes if no signal sensed
Phase Control 0 & 180 degrees
Upper frequency limit 40 – 120 Hz variable
Lower Frequency Limit 20 Hz (Typical IEC room)
Sold As Single Unit
Power Consumption 400 W / 0.5 W in Standby (ErP approved)
Bass EQ Profiles 1: Movie2: Music3: Impact
Mains Input Voltage 110 – 120 Vac /220 – 240 Vac 50/60 Hz (Electronically Auto selected)
Drive Unit Complement 1 x 12" C-CAM subwoofer driver featuring triple suspension and 3" long throw voice coil

Dimensional parameters

Weight (without packaging) 20.1 kg (44 lb 5 oz)
Dimensions (Including Grille, Amp and Feet) 370 x 340 x 410 mm (149/16" x 133/8" x 161/8”)
Dimensions (without grid and terminals (HxWxD)) 340 x 340 x 380 mm (133/8" x 133/8" x 1415/16”)
